High Speed Digital Textile Printer for direct printing on fabric with 2 year warrantee

High Speed Digital Textile Printer for direct printing on fabric with 2 year warrantee

    • High Speed Digital Textile Printer  for direct printing on fabric  with 2 year warrantee
    • High Speed Digital Textile Printer  for direct printing on fabric  with 2 year warrantee
    • High Speed Digital Textile Printer  for direct printing on fabric  with 2 year warrantee
    • High Speed Digital Textile Printer  for direct printing on fabric  with 2 year warrantee
  • High Speed Digital Textile Printer  for direct printing on fabric  with 2 year warrantee

    Product Details:

    Certification: ISO / CE
    Model Number: YS1808 / YS1816

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: negotiation
    Packaging Details: wooden case
    Delivery Time: 45 working days after received deposit
    Supply Ability: 10 sets per month
    Contact Now
    Detailed Product Description
    Printer Speed: 120-200m2/hour Fabric Transport: Belt / Direct Priting On Fabric
    Warrantee: 2 Year S Color: 4- 8 Colors
    Head Clean System: Automatic Systerm,Positive Pressure And Wiper Rip: Neostampa / Texprint
    Machine Width: 180cm Machine Weight: 4600KG
    CBM: 1 Set Load In 1*40'' Container


     Production Digital Textile Printer Machine Ricoh Gen5 Print Head

     High Speed Digital Textile Printer  for direct printing on fabric  with 2 year warrantee

                                                   Print head 2 years warrantee!

    Advantage:

    Stable :unattended production.
    High speed: 2000m/day
    Low printing cost:7-8g/m2
    Low investment:min. $45000.00-$78000.00

    1) Technical data



    Product mode YSR1808
    Print head 8-16pcs Ricoh Gen5E print head
    Fabric conveyance mode Adhesive belt with cleaning and heating system
    Maximum printing width 1800mm
    Maximum medium width 1850mm
    Maximum printing resolution 1200DPI
             2 pass 600*600dpi 110-120m2/h
    Speed        3 pass 600*900 dpi 70-80m2/ h
             4 pass 600*1200dpi 55-60m2/h top high quality
    Print software Neostampa / Texprint (origin)
    Printing part introduction Auto negative pressure ink supply,auto up & down of carriage,auto print head clean,auto print head capping
    Belt system introduction Auto dry & take-up system,auto belt cleaning system,no roll seal on fabric(roller fore and aft moving)
    Dryer unit Aluminum foil heater,infrared heater and hot wind
    Ink Type reactive , disperse or acid ink,pigment
    Ink color Cyan,Magenta,Yellow,Black,Orange,Red,Blue, Gray
    Interface GBE,Optical fiber
    Print head height Height adjustable1.530mm) to adapt medium of different thickness
    Power voltage 380V,3L+N+G(with independent reliable effective earth wire)
    Power frequency 50HZ/60HZ ±1HZ
    Power consumption printer 10kw,dyer 16kw
      Printer 4250*2200*1950mm (L* W* H)
      Dryer 2700*2200*2300mm
    Measurement(with wooden case) Ink cabinet 1900*700*1000mm
      Electric cabinet 1050*450*1700mm
      Fabric feeder(optional) 2580*1200*1950mm
    Weight G.W:4800kg                 N.W.:4200KG



    High Speed Digital Textile Printer  for direct printing on fabric  with 2 year warranteeHigh Speed Digital Textile Printer  for direct printing on fabric  with 2 year warrantee

    2) Main feature:


    • Printing width from1800mm
    • From 7 to 35 pl drop size
    • From 600-1200dpi
    • Print height from1.5mm to 3 mm automatic adjustment
    • With belt systemAuto up and down of carriage
    • Auto printhead cleaning
    • Auto printhead capping
    • Auto negative pressure ink supply
    • Auto dry and take-up system
    • Auto feeding adjustment system
    • Auto belt cleaning system

    .



          3) Main parts  :

    • Fabric transportation: Habasit industrial belt.Origin from Swiss Habasit.
    •  Printhead:Ricoh  Japan
    • Software:TEXPRINT / Nostampa
    • Japan Panasonic servo motor & German speed reducer.
    • Printhead moving guider :Germany


    4) Printing processing:

    • Reactive ink:  coating--digital printing --steaming--washing—drying
    • Dispers ink:   coating--digital printing --steaming--washing--drying
    • Pigment ink:  coating---digital printing—drying


    5) Ink type:

    • Acid inks :on polyamide lycra, wool, silk
    • Pigment ink :any kind of fabric
    • Disperse inks: directly onto polyester and blends
    • Reactive inks: on all natural fibers such as cotton,silk,wool,etc


    6) Wuarantee:

      1 year  for machine,2 years for pritnhead ,including install,testing and training in your factory.






    Vidoe youtube:



    1)DX5 introduce :https://youtu.be/LLP4SnbAtbg
    2)Ricoh Gen5 : https://youtu.be/VFa-ayJ8Jyk
